| enum | InputType { InputType::Floating = 0x0,
InputType::PullUp = 0x1,
InputType::PullDown = 0x2
} |
| |
| enum | InputTrigger : uint32_t {
None = 0x00u,
LowLevel = 0x01u,
HighLevel = 0x02u,
BothLevels = LowLevel | HighLevel,
FallingEdge = 0x04u,
RisingEdge = 0x08u,
BothEdges = FallingEdge | RisingEdge,
All = BothLevels | BothEdges
} |
| |
| enum | OutputType { PushPull
} |
| |
| enum | OutputSpeed { Slow = 0,
Fast = 1
} |
| |
| enum | DriveStrength { mA_2 = 0,
mA_4 = 1,
mA_8 = 2,
mA_12 = 3
} |
| |
| enum | SlewRate : uint8_t { Slow = 0,
Fast = 1
} |
| |
| enum | Port { Bank0,
Qspi
} |
| |
|
|
| MODM_FLAGS32 (InputTrigger) |
| |
| Enum Values | Documentation |
|---|
| Floating | floating on input
|
| PullUp | pull-up on input
|
| PullDown | pull-down on input
|
The documentation for this struct was generated from the following file:
